Hydraulic valves and fittings test stand

MT 162 is used for pressure testing of various types of valves and fittings. The unit can be used to test if the valve opens and closes easily under pressure, and if the housing and seals can withstand the test pressure. A manually operated piston pump draws water from the storage tank, fills the valve interior, and generates the test pressure. Learn about Hydraulic valves and fittings test stand specifications for optimal educational outcomes.. A manometer indicates the test pressure. The welded-in collector tray is fitted with a ball valve to allow it to be drained. Learn about Hydraulic valves and fittings test stand for educational labs for optimal educational outcomes.. The valve under test is attached to a mounting flange and sealed by a blank flange. The piston pump and mounting flange are interconnected via a pressure hose. Learn about Hydraulic valves and fittings test stand manufacturers for optimal educational outcomes.. The test stand includes its own storage tank so it can be operated independently of a water pipe supply. The tank must be topped up occasionally. Learn about Hydraulic valves and fittings test stand price for optimal educational outcomes..

• test stand on which to mount industrial valves and fittings
• pressure testing of valves and fittings
• hand-operated piston pump to generate the test pressure, a return valve to relieve the system pressure, and a manometer for pressure measurement
• 2 different sizes of mounting flange with blank flange and flange seal
• connection of pump and test flange via pressure hose
• test medium: water
• mobile frame with collector tray and ball valve to drain
• water storage tank
• part of the Practice Line for assembly, maintenance and repair
