Hydrometer Test Set

STANDARDS COMPLIANCE :

COMPLIED AS PER ASTM D422; AASHTO T88

Application :

This equipment is used to determine the quantitative size distribution of very fine particle in soils such as clay and silt.

Models Available :

Two models are available

• AECE2086 Hydrometer Test Set is Supplied with Hydrometer Water Bath, Circulation Pump, Heater, High Speed Stirrer, 6 ° 1000 ml Sedimentation Cylinder, 0.995 to 1.038 g/ml range 151 H Hydrometer, 1 kg Sodium Hexametaphosphate and 600 ml Beaker.

• AECE2087 Digital Hydrometer Test Set is Supplied with Digital Hydrometer Water Bath, Circulation Pump, Heater, High Speed Stirrer, 6 ° 1000 ml Sedimentation Cylinder, 0.995 to 1.038 g/ml range 151 H Hydrometer, 1 kg Sodium Hexametaphosphate and 600 ml Beaker.

Hydrometer Water Bath :

• The Hydrometer Water Bath, circulation unit, ambient to 35°C working temperature, 50 L capacity tank with 8 pieces Sedimentation cylinder capacity. The Water Bath is available in two models with Analogue and Digital Indicator.

High Speed Stirrer :

• High Speed Stirrer operates at over 10,000 rpm, includes dispersion cup, stirring paddle, automatic switch-on by positioning bowl.

Ordering Information :

• – 5 to 60 g/l range 152 H Hydrometer should be ordered separately.
• Cooling coil and clamps should be ordered separately.

Dimensions (cm) :

35°65°57

Weight (kg) :

25

Power Supply :

220 V, 50–60 Hz, 1 ph
