Information Optics Experiment Kit

The Information Optics Experiment Kit is designed to provide practical training in spatial frequency analysis, optical Fourier transformation, holography, and image processing. By combining theoretical concepts with hands-on experimentation, the kit enables students to explore key principles of information optics and gain a deeper understanding of how light can be manipulated for imaging and optical signal processing applications. The modular design allows users to assemble various optical configurations and investigate the relationship between spatial frequency spectra, image formation, diffraction, and holographic recording. Through these experiments, students develop valuable laboratory skills while reinforcing their understanding of modern optical techniques. The detailed instructional manual includes experimental configurations, theoretical principles, operating procedures, and setup guidelines, making the kit suitable for university-level optics and photonics education. Physics Lab Experiments from Atico Exports.

Holographic Photography :

• Study the recording and reconstruction of holograms using interference between reference and object beams to create three-dimensional images.

Holographic Grating Fabrication :

• Create holographic gratings using laser interference patterns and investigate their diffraction properties and optical applications.

Abbe Imaging and Spatial Light Filtering :

• Explore Abbe’s theory of image formation and perform spatial filtering techniques for frequency-domain image analysis and enhancement.

Theta Modulation :

• Investigate spectral modulation and pseudo-color effects for optical image processing and color encoding applications.

• Holographic Photography and Grating Fabrication
• Abbe Imaging Theory and Spatial Filtering
• Theta Modulation Experiments
• Comprehensive Information Optics Studies
• Detailed Instruction Manual

Laser :

• Wavelength: 632.8 nm
• Output Power: >1.5 mW

Rotary Slit :

• Single-Sided Type
• Slit Width: 0–5 mm (Continuously Adjustable)
• Rotation Range: ±5°

White Light Source :

• Tungsten-Bromine Lamp, 12 V / 30 W, Variable Output

Filtering System :

• Low-Pass
• High-Pass
• Band-Pass
• Directional
• Zero-Order

Fixed Ratio Beam Splitters :

• 5:5 and 7:3 Ratios

Adjustable Diaphragm :

• 0–14 mm

Grating :

• 20 Lines/mm

He-Ne Laser :

• Quantity: 1

White Light Source :

• Quantity: 1

XYZ Translation Stage on Magnetic Base :

• Quantity: 1

XY Translation Stage on Magnetic Base :

• Quantity: 1

Z Translation Stage on Magnetic Base :

• Quantity: 3

Universal Magnetic Bases :

• Quantity: 4

Two-Axis Mirror Holders :

• Quantity: 2

Lens Holders :

• Quantity: 2

White Screen :

• Quantity: 1

Plate Holder :

• Quantity: 1

Variable Diaphragm :

• Quantity: 1

Two-Axis Adjustable Plate Holder :

• Quantity: 1

Sample Stage :

• Quantity: 1

Adjustable Slit :

• Quantity: 1

Ground Glass Screen :

• Quantity: 1

Paper Clip Holder :

• Quantity: 1

Convex Lenses :

• Quantity: 3

Beam Expanders :

• Quantity: 2

Spatial Filter Set :

• Quantity: 1

Plane Mirrors :

• Quantity: 2

Transmissive Grating :

• Quantity: 1

Two-Dimensional Cross Grating :

• Quantity: 1

Fixed-Ratio Beam Splitters :

• Quantity: 2

Character with Grid :

• Quantity: 1

Theta Modulation Plate :

• Quantity: 1

Demonstration Object :

• Quantity: 1

Small White Board :

• Quantity: 1

Silver Salt Holographic Plates :

• Quantity: 1 Box
