Intelligent Digital Display Heating Mantle ALB429

Intelligent Digital Display Heating Mantle is a tabletop laboratory heating unit designed for precise temperature control of large-volume liquid samples. It features a PID temperature controller with inner and outer thermocouples for accurate monitoring of both the heating mantle and liquid temperature. The unit includes a digital display and a self-tuning mechanism to maintain the set temperature, providing reliable heating up to 380°C with a maximum temperature resistance of 450°C. Manufactured by Atico Export India.

Used in industrial, agricultural, civil, healthcare, scientific research, technology laboratories, and other laboratory applications.

Capacity :

• 30 L

Power :

• 3500 W

Temperature :

• 380°C

Temperature Accuracy :

• ±5°C

Voltage :

• 160 V to 240 V / 110 V to 120 V

Standard Accessories :

• Removable holder × 1
• Clamp with screw × 1
• Inner Thermocouple (4-pin) × 1
• Outer Thermocouple (4-pin) × 1
  • Stainless steel length: 235 mm
  • Wire length: 1000 mm
• Magnetic bead × 1
  • Designed specifically for round-bottom flasks
  • PTFE coated
  • Length: 20 mm
  • Diameter: 10 mm

• 30 L capacity
• Continuous working time
• Alkali-free glass fiber
• PID temperature control
• Inner and outer thermocouple for precise temperature measurement
• Customized mantle available
• Insulating course material of alumina silicate fiber
• Self-tuning mechanism for automatic temperature stabilization
