Intelligent linear expansion coefficient Physics Lab Experiment Setup by ATICO EXPORT

This experiment system is designed for studying displacement measurement techniques and the thermal expansion properties of materials. It enables the calibration of displacement sensors and the determination of the linear expansion coefficient of materials through controlled heating and precise measurement methods. The system provides an effective platform for understanding thermal expansion behavior and displacement sensing technologies.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Calibration and Verification of Displacement Sensors
• Measurement of the Linear Expansion Coefficient of Materials

Heating Mode :

• DC 0–30 V Intelligent Control
• Heating Power: 50 W

Temperature Range :

• 50°C–120°C
• Digital Display
• Constant Temperature Stability: ±0.1°C

Voltage Measurement Range :

• 0–1.999 V
• 0–19.99 V

Temperature Measurement :

• Range: -50°C to 125°C
• 3½-Digit Digital Display
• Accuracy: ±0.1°C

Calibration Device :

• Micrometer Calibration Device
