This advanced optics experiment kit is designed for comprehensive studies in interferometry, diffraction, and polarization. It enables students to construct various interferometers, investigate Fresnel and Fraunhofer diffraction, analyze light polarization, and measure the refractive index of air using precision optical components. The modular design makes it suitable for undergraduate, postgraduate, and research laboratories.
Technical Specifications
Parts Included :
He-Ne Laser (>1.5 mW, 632.8 nm) – 1
Transversal Measurement Stage (80 mm Travel, 0.01 mm Accuracy) – 1
Photocurrent Amplifier – 1
Manual Counter (4-digit, 0–9999 Counts) – 1
Air Chamber with Pressure Gauge – 1
Magnetic Bases with Post Holders – 3
Universal Carriers – 2
X-Translation Carriers – 2
X-Z Translation Carrier – 1
Optical Rail (1 m, Aluminum) – 1
Two-Axis Mirror Holders – 2
Lens Holders – 2
Plate Holder – 1
White Screen – 1
Aperture Adjustable Bar Clamp – 1
Adjustable Slit – 1
Laser Tube Holder – 1
Optical Goniometer – 1
Polarizer Holders – 3
50:50 Beam Splitters – 2
Polarizers – 2
Half-Wave Plate – 1
Quarter-Wave Plate – 1
Black Glass Plate – 1
Plane Mirrors (Ø36 mm) – 2
Lenses (f = 6.2 mm and f = 150 mm) – 1 each
Transmission Grating (20 lines/mm) – 1
Single Slits: 0.06 mm and 0.10 mm
Multi-Slits: 2, 3, 4, and 5 Slits
Slit Width: 0.03 mm
Center-to-Center Spacing: 0.09 mm
Circular Apertures: 0.05, 0.10, 0.20, 0.30, 0.40, and 0.50 mm
Square Apertures: 0.05, 0.10, 0.20, 0.30, 0.40, and 0.50 mm
Features & Benefits
Modular optical platform supporting interferometry, diffraction, and polarization experiments.
Precision optical components provide accurate alignment and repeatable measurements.
Suitable for advanced optics, laser physics, and optical engineering laboratory applications.
