Interferometer Physics Mechanics Science Kits for Lab Use in Schools & Colleges ATICO Export

Now with ultrasound:

• Traditional Michelson laser interferometers are often too expensive for full classroom use

• This INTERFEROMETER experiment set offers an affordable alternative for schools and even pair work

• Ultrasound provides key advantages over laser light:

• Safer for classroom use

• Allows a very clear and visible experimental setup

• Provides highly comparable accuracy

• Students assemble and adjust the apparatus themselves

• This improves understanding of both the experiment and the equipment

• The measuring amplifier in the control unit produces clear maxima and minima

• Analog meter readings can vary up to one-third of the full scale for precise observation

• A perforated slide acts as a semi-transparent mirror

• It is specifically optimized for the wavelength of ultrasonic waves

Included items:

• 1 × Storage case
• 1 × Inlay with cut-outs for apparatus, IN
• 1 × Control unit
• 1 × Transmitter with parabolic fitting
• 1 × Receiver with parabolic fitting
• 1 × Base plate, IN
• 2 × Fixed reflector plates
• 1 × Movable reflector plate
• 1 × Perforated aperture
• 2 × Attachment arms
• 1 × Screws in box, IN
• 1 × Experiment lead, 25 cm, red
• 1 × Experiment lead, 25 cm, blue

Additionally required:

• Multimeter AMM 3000
