Investigation of cam mechanisms

Cam mechanisms play an important role in the conversion of rotary motion into oscillatory motion. The most common application of cam mechanisms is the activation of valves in engines. This application is highly dynamic: valves must be opened and closed in very quick succession. Learn about Investigation of cam mechanisms specifications for optimal educational outcomes.. The contact between the valve and a cam must not be lost, otherwise it would result in uncontrolled oscillations, valve float and possible damage to the engine.

• investigation of cam mechanisms
• cam-shaped cam members: tangent cam, hollow cam, 2 circular arm cams with different head radius
• 2 different engaging members: flat receiver with plunger or rolling receiver with plunger
• 3 interchangeable return springs and spring preload
• drive motor with variable speed
• oscillating mass can be increased with 5 additional weights
• mechanical drum recorder with nib and coated paper
• optical speed sensor
• transparent protective cover for safe operation
