J-Ring

• J-Ring Narrow Gap with °18 mm ° 16 smooth bars is manufactured from stainless steel.
• J-Ring Wide Gap with °18 mm ° 12 smooth bars is manufactured from stainless steel.

Standards Compliance :

• Complied as per EN 12350-12

Application :

• The J-Ring test is used for determining the passing ability, the flow spread, and the flow time of self-compacting concrete (SCC) as the concrete flows through the J-Ring apparatus.

Base Plate :

• 900 ° 900 ° 3 mm square, made of stainless steel with engraved circles of °200 mm and °500 mm conforming to EN 12350-8.

Slump Cone :

• Manufactured from sheet steel protected against corrosion, with top °100 mm, base °200 mm and height 300 mm.

Steel Weighted Collar :

• Used to stabilize the slump cone during J-Ring or slump flow tests.

Standard Supply :

• J-Ring Narrow Gap Test Set is supplied with J-Ring Narrow Gap, Slump Cone and Base Plate.
• J-Ring Wide Gap Test Set is supplied with J-Ring Wide Gap, Slump Cone and Base Plate.

Optional Accessories :

• Steel weighted collar should be ordered separately.
