Jacketed Glass Reactor ALB364

Jacketed Glass Reactor is designed for chemical synthesis, distillation, reflux, and stirring applications under controlled temperature conditions. It features a borosilicate glass vessel, corrosion-resistant PTFE wetted components, and a durable stainless steel frame for reliable laboratory performance. Manufactured by Atico Export India.

Used for biochemical and chemical synthesis, reaction, distillation, reflux, and stirring processes under constant temperature conditions.

Reaction Volume :

• 10 L

Jacket Volume :

• 3 L

Rotating Speed :

• 0 to 600 rpm

Working Temperature Range :

• -60°C to 200°C

Neck Number on Lid :

• 6

Maximum Jacket Pressure :

• 0.5 bar

Overall Dimensions :

• 650 × 500 × 2000 mm

Motor Power :

• 120 W

• 304 stainless steel frame with epoxy coating
• Borosilicate 3.3 glassware for excellent chemical and physical performance
• Glass/PTFE wetted components for outstanding corrosion resistance
• Heating fluid inlet/outlet ports: 20 mm glass hose barb
• Pressure rating: Full vacuum to atmosphere
• Cooling area: 0.2 m² (double coil)
