Jolting Apparatus

Usage :

• Suitable for laboratory experiment

Construction :

• Solid-Robust Construction

System :

• Rectangular Table rigidly connected by two support arms to spindle

Horizontal Distance :

• 800 mm from centre of table.

Other Parts :

• Projecting Lug with Plane Face on upper side of table

Cam Shaft :

• Material : Hardened Steel, coupled to motor and gearbox via a V-belt and pulleys.

Speed :

• 60 RPM

Speed Measurement :

• Stroke Counter fitted

Locating Pins :

• Provided for mounting mould compartments

Power Supply :

• 220 Volts AC, 50 Hz, Single Phase

Mould :

• Material : Steel with base plate, 3 compartments type, Size : 40 x 40 x 160 mm

Standards Compliance :

• IS 1727 1967, IS 4031 1968, ASTM C 394, C 64
