Jolting Table Apparatus

The apparatus consists of a table holding the mould, seated on a rotating cam driven at 60 rpm.

Standards Compliance :

• COMPLIED AS PER EN 196-1, EN ISO 679

Application :

• Used to compact cement mortar prisms 40 ° 40 ° 160 mm in the three-gang mould containing cement specimens.

Optional Model :

• A Jolting Table Apparatus with soundproof safety cabinet is also available.
• The cabinet is internally lined with soundproofing material to reduce sound level in compliance with CE directives.

Operating Parameters :

• The drop height is 15 mm.

Control :

• Machine is equipped with a digital counter which provides automatic shut-off at the end of preset drop numbers.
• A rapid mould lock and release system allows easy and quick operation.

Structural Design :

• The supporting frame is designed to ensure precise dimensional stability, flatness, and correct centering of the three-gang mould on the table.

Safety & Durability :

• The motor and gearbox assembly are enclosed in a protective housing, improving user safety by keeping moving parts inaccessible and extending gearbox life.

Dimensions (cm) :

• AECE2161/A - 35 ° 105 ° 60
• AECE2161/B - 50 ° 145 ° 60

Weight (kg) :

• AECE2161/A - 55
• AECE2161/B - 125
