Kaplan turbine

Kaplan turbines are characterised by an axial flow through and adjustable blades. They are used at low heads and very large flow rates. Because Kaplan turbines belong to the double regulated turbines, meaning that both the guide vanes and the blades can be adjusted, they are suitable for operation at changing operating conditions. Learn about Kaplan turbine exporters for optimal educational outcomes.. Compared to fixed-blade propeller turbines, Kaplan turbines offer a high efficiency over a wide range of operating. In practice, Kaplan turbines are used in run-of-the river power plants. Learn about Kaplan turbine suppliers for optimal educational outcomes..

• transparent pipe element for observing the operating area
• adjustable guide vanes for setting different angles of the water inlet into the turbine
• rotor with adjustable blades for setting different velocities at the rotor
• recording the curves of a Kaplan turbine and investigating the influence of the guide vane and blade position
• loading the turbine by use of a wear-free and adjustable eddy current brake
• non-contact speed measurement and force sensor at the brake for measuring the torque
• pressure sensor at the turbine inlet
• speed, torque and pressure displayed on the switch cabinet
• water supply, flow rate measurement and data processing software via base unit
