Kinematic model: crank mechanism

The crank mechanism is the functional group of machines that converts a uniformly rotating (rotational) motion into a reciprocating (translational) motion or vice versa. Crank mechanisms are used in engines, pumps or presses.

• investigation of a crank mechanism
• adjustment of the crank radius at three positions of the crank on the crank disk
• adjustment of the angle by turning the crank disk
• measure the stroke on the cylinder
• pivoting cylinder can be blocked to study the crank mechanism with either a fixed or oscillating cylinder
