Kinematic Viscosity Bath ALB56

Kinematic Viscosity Bath is designed for viscosity testing in accordance with ASTM D445 standards. It operates within a temperature range of 20°C to 100°C and accommodates up to four samples simultaneously for efficient testing. The bath ensures excellent temperature stability and uniform heat distribution for accurate and reliable viscosity measurements. It features a 7-inch color LCD screen for convenient monitoring and operation. Manufactured by Atico Export India.

• Petroleum testing laboratories
• Lubricating oil analysis
• Chemical laboratories
• Quality control laboratories
• Research laboratories
• Industrial testing facilities

Testing Range :

• 0.5 to 20,000 mm²/s (with different viscosity tubes)

Temperature Control Range :

• 20°C to 100°C

Temperature Accuracy :

• ±0.01°C

Working Temperature Range :

• 0°C to 40°C

Relative Humidity :

• Less than 80%

Sample Capacity :

• 4 samples

Timing Range :

• 0.1 to 9999.9 seconds

Timing Accuracy :

• ±0.1 second

Homothermic Bath :

• 300 × 300 mm double-layer bath

Temperature Testing Component :

• Imported platinum electric resistance sensor (PT100)

Display :

• 7-inch color LCD

Data Output :

• High-speed, low-power thermal printer with 55 mm printing paper

Heating Power Consumption :

• 800 W

Power Supply :

• AC 220 V ±10%, 50 Hz ±5%

Dimensions :

• 360 × 370 × 520 mm

Net Weight :

• 15 kg

Gross Weight :

• 20 kg

Standard Accessories :

• Glass cylinder × 1 pc
• Water bath top cover assembly × 1 set
• Control cable × 1 pc
• Fuse tube × 1 pc
• Capillary viscometer × 4 pcs
• Wash ears ball × 1 pc

• Complies with ASTM D445 standard
• Simultaneous testing of up to four samples
• Three-point vertical capillary holder
• Precision digital temperature controller
• User-friendly 7-inch LCD interface
• Flexible viscosity tube selection
• Double-layer constant temperature bath
• High-speed thermal printer
• Automatic viscosity calculation
• Spark-free solid-state relay operation
• PC connectivity for data transfer
• USB data storage support
