Knife Mill (Net weight – 10 kg)

The Knife Mill (Net weight – 10 kg) is the ideal instrument for grinding and homogenizing foods and feeds. With two sharp, robust blades and a powerful 1000 W motor, it allows to process sample volumes up to 0.7 liters quickly and effectively. The KNIFE MILL (NET WEIGHT – 10 KG) is not only ideal for homogenizing substances with a high water, oil or fat content but is also perfectly suited for grinding dry, soft and medium-hard products. The quick homogenization process without noteworthy temperature rise ensures preservation of volatile sample components.

ACCESSORIES & OPTIONS :

A range of different containers, lids and knives makes the KNIFE MILL (NET WEIGHT – 10 KG) a truly universal device, suitable not only for processing food and feed samples but a wide range of materials.

Patented gravity lid

• Automatically adjusts the grinding chamber volume to the changing sample volume.

Gravity lid with overflow channels

• Ideally suited to homogenize samples with a high water content.

Stainless steel container

• Minimum wear when hard sample materials are processed.

Stainless steel container with baffles

• The baffles contribute to a thorough mixing of the sample.

Reduction lid

• Reduces the chamber volume to 0.5 or 0.3 liter for optimum homogenization of small sample volumes.

Serrated blade knife

• Used for particularly tough samples such as fatty, streaky meat.

Full metal knife

• With 2 blades, it is suitable for cold grinding and cutting hard samples.

Cryokit

• For homogenizing sticky samples with dry ice

FUNCTIONAL PRINCIPLE :

Two sharp, robust blades rotate in the center of the grinding container. Depending on the rotational direction, size reduction is effected with the blunt side (preliminary size reduction) or the sharp side (fine grinding). The knife is directly driven by a powerful motor of 1000 W. A pre-selectable speed which is maintained electronically ensures optimum adaptation to individual application requirements as well as reproducible grinding results.

Applications :

• size reduction, homogenization and mixing

Field of application :

• agriculture, biology, food, medicine / pharmaceuticals

Feed material :

• soft, medium-hard, elastic, containing water / fat / oil, dry, fibrous

Size reduction principle :

• cutting

Material feed size :

• 40 mm

Final fineness :

• < 300 °m

Batch size / feed quantity :

• with standard lid 700 ml
• with reduction lid 150-300 ml
• with gravity lid 300 - 600 ml

Grinding chamber volume :

• with standard lid 1000 ml
• with reduction lid 250 ml/500 ml
• with gravity lid 400 - 800 ml

Speed setting :

• digital, 2,000 - 10,000 min-1 (14,000 min-1 BOOST)

Material of grinding tools :

• Blade: stainless steel / titanium
• Fixation of blade: PVDF / stainless steel
• Container: autoclavable plastic / plastic PP / stainless steel

Setting of grinding time :

• digital, 1 s - 3 min

Interval operation :

• yes

Storable :

• SOPs 8 programms / 4 sequences

Drive :

• series-characteristic motor

Drive power :

• ~ 1000 W

Electrical supply data :

• different voltages

Power connection :

• 1-phase

Protection code :

• grinding chamber and keypad IP 42

Power consumption :

• ~ 1000 W

W x H x D closed :

• 350 x 275 x 392 mm (opened: 350 x 410 x 553)

Net weight :

• ~ 10 kg

Standards :

• CE
