L-BOX

The L-Shape Box is designed for ease of cleaning the vertical and horizontal hoppers.
The distance between diameter bars can be set between 41 ° 1 mm or 59 ° 1 mm.

Standards Compliance :

• Complied as per EN 12350-10

Application :

• The L-Shape Box is used for evaluation of self-compactability (confined flow ability) of freshly mixed self-compacting concrete.
• The box gives the opportunity to evaluate different properties such as filling ability, passing ability, and resistance to segregation.

Standard Supply :

• The L-Box apparatus is supplied complete with filling hopper.

Dimensions (cm) :

• 30 ° 100 ° 135

Weight (kg) :

• 35
