EXPERIMENT: REALIZATION OF SERIES AND PARALLEL RESONANCE & DETERMINATION OF L AND Q VARIATIONS
EXPERIMENT SETUP CONSISTS OF:
- LCR Resonance Kit – With digital current meter 0–20 mA, two unknown inductors, set of three resistors and three capacitors, set of patch cords, cabinet made of acrylic
- Signal Generator – Microcontroller-based digital signal generator producing frequency up to 1 MHz, 20 V p-p output in sine, square, triangular and pulse waveforms, digital display for frequency and waveform display, connecting wires and manual provided
Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.
