Laboratory Leach Reactor

A heat-controlled laboratory leaching test agitator designed for leaching and agitation of slurries. It is compact, rugged, and suitable for laboratory and small pilot plant operations, particularly for hydrometallurgical testing.

• Gold cyanidation testing
• Silver leaching tests
• Copper acid leaching
• Hydrometallurgical research
• Laboratory slurry agitation and reaction studies

Volume :

• 1.5 / 3 / 5 L

Impeller Speed :

• 0 ~ 2800 (adjustable) RPM

Impeller Diameter :

• 31 / 39 / 48 mm

Feed Size :

• 0.05 – 0.2 mm

Dimensions :

• 450 × 340 × 475 mm

Weight :

• 68 kg

Air Delivery Pump :

• CX-0098

Heater :

• AC220V / 250W

Motor :

• 220V / 2800 RPM

Agitator speed :

• 0 to 2800 RPM

Heater power :

• 250 W

Temperature control :

• Up to 50°C

Tank capacities :

• 1.5 L
• 3 L
• 5 L

Agitator sizes :

• 31 mm
• 39 mm
• 48 mm

• Built-in air pump with controllable airflow
• Variable speed agitator
• Integrated heating system with temperature control
• Digital display for speed adjustment
• Built-in thermometer for slurry temperature monitoring
• Multi-functional reactor design
• Compact and durable construction
