Lathe gear

The lathe gear has all the essential features and characteristics of a workshop lathe: a shiftable main gear, a feed gear for driving the lead screw (Norton gear), a change gear and a tumbler gear.

• design and function of a lathe gear
• fully functional experimental unit
• optimum insight thanks to open design
• shiftable main gear
• Norton gear as feed gear to drive the lead screw
• change gear and tumbler gear
• record the feed on paper via recorder drum on the primary spindle
• driven by hand crank
