This experimental unit provides a comprehensive experimental introduction to the fundamentals of control engineering using an example of level control.
Technical Specifications
level control with components commonly used in industry
controlled system: transparent tank with overflow and scale
measuring element: pressure sensor for level measurement
multi-functional digital industrial controller
generation of disturbance variables by ball valve with scale in outlet
actuator: electromagnetic proportional valve
process variables X and Y accessible as analogue signals via lab jacks
