A high-capacity test stand for four-cylinder petrol or diesel engines delivering up to 75kW. It uses an eddy current brake to generate and measure engine loads.
Technical Specifications
load unit with air-cooled eddy current brake (75kW max)
force transmission via rotationally elastic coupling and jointed shaft
large stabilization tank for intake air (220L)
supports full load and partial load characteristic modes
digital measurement of air consumption, speed, fuel consumption, and oil pressure
software for data acquisition via USB under Windows 11
