Losses in pipe elements Deluxe

Pressure losses in pipe sections can have various causes, such as acceleration, deceleration, deflection or friction. Pressure loss is often caused by a combination of several factors. This must be taken into account when designing piping systems. Learn about Losses in pipe elements exporters for optimal educational outcomes..

• investigate pressure losses at valves and pipe fittings
• 7 individually closable pipe sections with various pipe elements: nozzle, orifice, bends, valve, ball valve
• comparison of ball valve and needle valve
• flow rate in the pipe section can be adjusted via the base module
• automatic identification of accessories via RFID technology
• experiment execution and display of measured values via touch screen (HMI)
• network capability: access to ongoing experiments and their results from up to 10 external workstations simultaneously via the local network
• water supplied via the base module
