Low Temperature Grease Flow Tester for Fuel Testing Instrument

The Low Temperature Flow Tester is designed to evaluate the flow properties of lubricating greases under low-temperature conditions. These properties are important for grease performance in central lubrication systems, vehicles, and machinery operating in cold and harsh environments.

The instrument determines the flow pressure of lubricating grease at temperatures down to −50°C using the Kesternich method in accordance with DIN 51805. Its specialized cooling system enables rapid cooling to the required test temperature without an expensive external cooling device.

The system incorporates precision-engineered components for accurate measurements, including at very low pressure ranges. A touch-screen interface with an integrated programmable logic controller (PLC) allows operators to adjust test parameters, select predefined settings, and configure customized test procedures. Remote monitoring and control are also supported through an app.

Manufactured by Atico Export for reliable low-temperature grease flow testing in lubricant testing and industrial research laboratories.

• Determination of lubricating grease flow pressure at low temperatures
• Evaluation of grease flowability in cold environments
• Testing lubricants used in central lubrication systems
• Assessment of grease performance in vehicles and machinery
• Quality control and research for industrial lubricants

Pressure Range :

• 0 to 3 bar

Pressure Resolution :

• Less than 1 mbar

Temperature Range :

• Ambient to −50°C

Temperature Resolution :

• Less than 1°C

Control System :

• Touch-screen PLC
• Integrated HMI software

Pressure Generation :

• Internally generated air pressure

Interface :

• Ethernet

Power Supply :

• 110–230 V, 50/60 Hz

Maximum Power Consumption :

• 350 W

Dimensions (L × W × H) :

• 17.3 × 12.6 × 9 inches (44 × 32 × 23 cm)

Net Weight :

• 55 lb (25 kg)

Standard Accessories :

• Basic machine
• Multi-range power supply
• PLC and HMI software
• One testing sleeve
• Three unloading containers
• Tooling set
• Documentation

• Designed for low-temperature grease flow testing
• Testing temperatures down to −50°C
• Integrated cooling system without requiring an expensive external cooling device
• Pressure measurement range of 0 to 3 bar
• High-resolution pressure measurement
• Touch-screen interface with integrated PLC
• Customized test settings available
• Predefined temperature selection and manual temperature adjustment
• Predefined pressure increase time of 30 seconds, with customization available
• User-selectable starting pressure
• Integrated help function in the human-machine interface (HMI)
• Remote monitoring and control through an app
• Ethernet interface
• Multi-range power supply
