LPG Copper Strip Corrosion Test Apparatusfor Petroleum Testing Equipment

The LPG Copper Strip Corrosion Test Apparatus is designed to evaluate the corrosiveness of liquefied petroleum gas (LPG) to copper. The test involves immersing a polished copper strip in an LPG sample inside a test cylinder at an elevated temperature. After one hour, the strip is removed and compared with the ASTM Copper Strip Corrosion Standards to assess the level of corrosion.

The system includes a temperature-controlled water bath capable of holding five LPG corrosion test cylinders in an upright position. The bath maintains the specified test temperature, while stainless steel cylinders provide secure containment of LPG samples during testing.

Manufactured by Atico Export for reliable LPG corrosion evaluation in petroleum testing and quality control laboratories.

• Evaluation of LPG corrosiveness to copper
• Copper strip corrosion testing of LPG samples
• Petroleum product quality control

Sample Capacity :

• Five LPG corrosion test cylinders

Temperature Range :

• Ambient to 100°F (37.8°C)

Temperature Control Stability :

• Exceeds ASTM requirements

Bath Medium :

• Water

Bath Capacity :

• 6.1 US gallons (23.1 litres)

Test Cylinder :

• Stainless steel construction
• 1/4-inch needle valves for purging and admitting LPG samples
• Dip tube with hook for suspending the copper strip
• Knurled threaded cap with O-ring gasket
• Hydrostatic test pressure: 1000 psig (6895 kPa)

Test Duration :

• One hour

Standard Accessories :

• LPG corrosion test cylinders
• Water bath
• Copper test strips
• Polishing materials
• ASTM Copper Strip Corrosion Standards

• Capacity for five LPG corrosion test samples
• Temperature-controlled water bath
• Maintains the specified test temperature of 100°F (37.8°C)
• Fully insulated water bath construction
• Polished stainless steel inner wall
• Powder-coated steel outer wall
• Stainless steel LPG corrosion test cylinders
• Needle valves for purging and admitting LPG samples
• Dip tube with hook for suspending the copper strip
• Knurled threaded cap with O-ring gasket for secure sealing
• Designed for comparison with ASTM Copper Strip Corrosion Standards
