Magnetic Hysteresis Loop and Magnetization Curve Experiment

Experiments :

• Measurement of the relationship between magnetic induction intensity (B) and position (X) within a magnetic sample using a digital Teslameter.

Experiments :

• Determination of the uniform magnetic field region along the X-axis.

Experiments :

• Study of magnetic sample demagnetization, initial magnetization curves, and magnetic hysteresis characteristics.

Experiments :

• Application of Ampere’s Circuital Law in magnetic field measurements.

Constant Current Source :

• 4½-digit digital display.
• Output Range: 0–600 mA.
• Continuously adjustable.

Magnetic Material Samples :

• Quantity: 2 samples.
• Rectangular bar configuration.
• Section Length: 2.00 cm.
• Width: 2.00 cm.
• Air Gap: 2.00 mm.

Digital Teslameter :

• 4½-digit display.
• Measuring Range: 0–2 T.
• Resolution: 0.1 mT.
• Supplied with Hall probe.

Designed For :

• Physics Lab Experiments from Atico Exports.
