Magnetoresistance effect combination Physics Lab Experiment Setup

This experiment system is designed for studying the operating principles, characteristics, and applications of magnetoresistive sensors. It enables the investigation of the relationship between the resistance of magnetoresistive elements and magnetic induction intensity, providing a practical understanding of magnetic field sensing technology. The system is suitable for laboratory studies in sensor technology, electronics, and applied physics.

Manufactured by Atico Export India.

Experimental Principle and Content

• Study of the Relationship Between Magnetoresistive Element Resistance and Magnetic Induction Intensity
• Investigation of the Basic Characteristics of Magnetoresistive Sensors
• Study of the Applications of Magnetoresistive Sensor Technology

Digital Gauss Meter :

• Measuring Range: 0–0.5 T

DC Power Supply 1 :

• Current Range: 0–500 mA
• Continuously Adjustable

DC Power Supply 2 :

• Current Range: 0–3 mA
• Continuously Adjustable

Voltage Measurement :

• Range: 0–199.99 mV
