Manuel Grinding Machine

Manual Grinding Machine is used as an alternative to rubber or sulphur capping methods.
Used to grind concrete cylinders, rocks, natural stones, tiles, block pavers, ceramic materials, etc.
Ensures high flatness and surface quality.
Maximum tolerance of flatness of compression bearing surface: 0.05 mm.
Deviation of perpendicularity of side faces: 0.5° for concrete samples.

Standards Compliance :

• Standards for Concrete Samples: Complied as per EN 12390-1, EN 12390-3, ASTM C31, C39, C192, C617
• Standards for Core Samples: Complied as per EN 12390-1, EN 12390-3, ASTM C42

Capacity :

• Standard use for °150 ° 300 mm cylinder samples.

Optional Accessories :

• Adaptor for °35–100 mm core samples should be ordered separately.

Dimensions (cm) :

• 80 ° 80 ° 130

Weight (kg) :

• 90

• Electrostatically painted steel body resistant to corrosion.
• Equipped with water inlet and outlet for safe operation and dust-free grinding.
• Used with diamond cutting wheel.
