Marshall Stability Test Machine with Load Ring

The Capacity Marshall Stability Test Machine with Load Ring 50 kN is used to determine the maximum load and flow values of bituminous mixtures. The machine comprises of a robust and compact two column frame with adjustable upper cross beam. The unit is a bench mounting compression frame with motor and worm gear housed within the base unit.

STANDARDS COMPLIANCE :

• COMPLIED AS PER EN 12697-34, 12697-23, 12697-12, 13108, ASTM D1559, AASHTO T245

Supply / Components :

• The Marshall Stability Test Machine with Load Ring is supplied complete with 50 kN capacity Load Ring with 0.01 mm resolution Analog Dial Gauge, 30 x 0.01 mm Analog Dial Gauge and Breaking Head (Stability Mould) for ° 4" Marshall samples.

Dimensions (cm) :

• 47x61x95

Weight (kg) :

• 89

Power Supply :

• 220 V, 50 Hz, 1 ph

Spare Parts & Accessories :

• Breaking Head (Stability Mould) for 4" Marshall samples
• Breaking Head (Stability Mould) for 6" Marshall samples
• Load Ring, 50 kN capacity with 0.01 mm resolution Analog Dial Gauge
• Dial Gauge, 30 x 0.01 mm
• Indirect Tensile Splitting Device for 4" Marshall samples
• Indirect Tensile Splitting Device for 6" Marshall samples
• Loading Strips, 100 mm, for Tensile Splitting Device
• Loading Strips, 160 mm, for Tensile Splitting Device
• Indirect Tensile Test Jig for Compacted Bituminous Samples with 30x0.01 mm Analog Dial Gauge for 100 mm (4") samples
• Indirect Tensile Test Jig for Compacted Bituminous Samples with 30x0.01 mm Analog Dial Gauge for 150 mm (6") samples

Optional Accessories :

• Breaking Head (Stability Mould) for 6" Marshall samples, Indirect Tensile Splitting Device for 4" Marshall samples, Indirect Tensile Splitting Device for 6" Marshall samples, Loading Strips, 100 mm, for Tensile Splitting Device, Loading Strips, 160 mm, for Tensile Splitting Device and Indirect Tensile Test Jig for Compacted Bituminous Samples with 30x0.01 mm Analog Dial Gauge for 100 mm (4") & 150 mm (6") samples should be ordered separately.

• Platen rate is 50.8 mm/min also maintained under load thanks to an overpowered electric motor.
• For safety, the up and down travel of the lower platen is limited the use of limit switches. The machine can be hand operated by a hand wheel for calibration purposes.
