Measurement of Air Density & Universal Gas Constant for Heat Physics Lab

This Measurement of Air Density & Universal Gas Constant for Heat Physics Lab is designed for studying the thermodynamic properties of gases and experimentally determining the density of air and the universal gas constant. The apparatus utilizes the vacuum method, combining a gravity bottle, vacuum pump, vacuum gauge, and precision mass measurement techniques to investigate the relationship between pressure, volume, temperature, and gas mass. Through practical experimentation, students can verify the ideal gas law, determine air density under ambient and standard conditions, and calculate the universal gas constant with high accuracy. The system provides an effective platform for thermodynamics and molecular physics laboratory studies.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Measure the Density of Ambient Air Using the Vacuum Method
• Convert Measured Air Density Values to Standard Conditions
• Compare Experimental Air Density Values with Theoretical Values
• Determine the Universal Gas Constant Using Pressure and Mass Measurements
• Study the Relationship Between Gas Pressure and Gas Mass
• Analyze Experimental Data Using Curve Fitting Techniques
• Verify the Ideal Gas Law Through Practical Experimentation

Educational Objectives

• Understand the Principles of Air Density Measurement
• Study the Universal Gas Constant and Its Significance
• Explore the Relationships Described by the Ideal Gas Law
• Learn Vacuum-Based Measurement Techniques
• Develop Skills in Experimental Data Collection and Analysis
• Gain Practical Experience in Thermodynamics and Molecular Physics

Rotary Vacuum Pump :

• Pumping Speed: 1 L/s
• Maximum Vacuum: 6 Pa
• Rotational Speed: 1400 rpm
• Power: 180 W

Vacuum Gauge :

• Measuring Range: -0.1 to 0 MPa
• Minimum Scale Division: 0.002 MPa

Electronic Balance :

• Capacity: 0–1000 g
• Readability: 0.01 g

Thermometer :

• Measuring Range: 0–50°C
• Minimum Division: 0.1°C

Standard Supply

• Vacuum Pump × 1
• Vacuum Gauge × 1
• Vacuum Valve × 1
• Gravity Bottle × 1
• Vacuum Tubes × 2
• Tee and Connector Set × 1 Set
• Base and Support Assembly × 1
• Electronic Balance × 1 (Optional)
• Thermometer × 1 (Optional)
• Instruction Manual × 1

• High-Performance Experimental System
• Simple Structure with Stable and Reliable Operation
• Accurate and Repeatable Measurements
• Cost-Effective Educational Apparatus
