Measurement of Photoelectric Characteristics of Photosensitive Sensors

This photoelectric characteristics experiment system is designed to study the electrical and optical behavior of various photosensitive devices. It enables students to measure the voltage-current and illumination characteristics of silicon photocells, photoresistors, photodiodes, and phototransistors using precision measuring instruments. Physics Lab Experiments from Atico Exports.

Experiments :

• Measure the Voltage-Current (V-I) and Illumination Characteristics of a Silicon Photocell and Photoresistor.
• Measure the Voltage-Current (V-I) and Illumination Characteristics of a Photodiode and Phototransistor.

Power Supply :

• DC -12 V to +12 V
• Adjustable
• 0.3 A

Light Source :

• Three illumination ranges
• Continuously adjustable for each range
• Maximum illumination >1500 lx

Digital Voltmeter (Measurement) :

• Three ranges: 0–200 mV, 0–2 V, 0–20 V
• Resolution: 0.1 mV, 1 mV, and 10 mV respectively

Digital Voltmeter (Calibration) :

• Range: 0–200 mV
• Resolution: 0.1 mV

Optical Path Length :

• 200 mm

Standard Accessories :

• Main Unit – 1
• Photosensitive Sensor Set – 1 (including mounting holder, calibration photocell, and four sensors)
• Incandescent Bulb – 2
• Connection Wires – 8
• Power Cord – 1
• Instruction Manual – 1
