Measuring Liquid Viscosity Capillary Method for Mechanics Physics Lab

This Measuring Liquid Viscosity Capillary Method for Mechanics Physics Lab is designed for determining the viscosity coefficient of liquids using the Capillary Method with an Ostwald Viscometer. The system measures the time required for a liquid to flow through a precision capillary tube under the influence of gravity, providing accurate and repeatable viscosity measurements. An integrated temperature control system allows experiments to be conducted under controlled thermal conditions, enabling detailed investigation of temperature effects on viscosity and fluid behavior. The apparatus also supports capillary action and surface tension studies, making it suitable for fluid mechanics, biophysics, medical physics, and educational laboratory applications.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Study the Principles of Poiseuille’s Law
• Measure the Viscosity Coefficient of Liquids Using the Ostwald Viscometer
• Investigate Capillary Flow Behavior in Liquids
• Measure Surface Tension Coefficients Through Capillary Action Experiments
• Analyze the Effect of Temperature on Liquid Viscosity
• Compare the Viscosity Characteristics of Different Liquids

Educational Objectives

• Understand the Principles of Viscosity and Fluid Flow
• Learn the Operation of an Ostwald Viscometer
• Study the Relationship Between Viscosity, Flow Rate, and Temperature
• Explore Practical Applications of Viscosity Measurement in Science and Industry
• Develop Skills in Experimental Measurement and Data Analysis

Temperature Controller :

• Temperature Range: Ambient Temperature to 45°C
• Resolution: 0.1°C

Stopwatch :

• Resolution: 0.01 s

Motor System :

• Adjustable Speed
• Power Supply: 4–11 V

Ostwald Viscometer :

• Capillary Tube Inner Diameter: 0.55 mm
• Capillary Length: 102 mm

Glass Beaker :

• Volume: 1.5 L

Pipette :

• Capacity: 1 mL

Standard Supply

• Controller Unit × 1
• Glass Beaker × 1
• Beaker Lid with Heater, Temperature Sensor, Capillary Holder and Connection Sockets × 1
• Magnetic Rotor × 1
• Ostwald Tubes × 2
• Rubber Air Pump × 1
• Connection Wires × 2
• Stopwatch × 1
• Pipette × 1
• Instruction Manual × 1

• Innovative Apparatus Design
• Variable and Controllable Temperature System
• High Measurement Accuracy
• Ideal for Biophysics, Medical Physics, and Fluid Mechanics Studies
