MEC - Deformation of frames Deluxe

A frame is a buckled beam with rigid corners that forms a so-called clearance profile. Frames are used in various shapes and can be made of different materials, e. g. Learn about MEC - Deformation of frames manufacturers for optimal educational outcomes.. metal, wood or composite materials.

• elastic deformation of a statically determinate or indeterminate frame under point load
• setup of the entire experiment arrangement in the mounting frame SE 200
• click system for simple, fast experimental setup without cabling
• cantilever beam for determining material and shape properties
• frame shapes: 1x U-shaped, 1x curved
• statically determinate or statically indeterminate mounting possible
• load via load unit SE 200.22 or vertical load SE 200.24
• multiple load application points possible
• automatic identification and assignment of accessories during setup and while conducting the experiment
• display of measured values in the software
• software via USB under Windows 11
• digital multimedia teaching material online in the Media Center: E‑Learning course, worksheets
