MEC - Friction on the inclined plane

Frictional forces are essential for machines. This applies to static friction in static applications and dynamic friction in dynamic applications.

• measurement of the static and dynamic friction coefficient on an inclined plane
• setup of the entire experiment arrangement in the mounting frame
• click system for simple, fast experimental setup without cabling
• inclined plane with electronic module for data acquisition and measured value display
• angle of the inclined plane manually adjustable
• friction body: 1x with wheels, 1x without wheels
• variable load for friction bodies: 5x 1N
• different material pairings possible
• slow experiment sequence by using optional flywheels
• all components clearly laid out and well protected in a storage system
• display of measured values for force, angle and displacement directly on the inclined plane and in the software
• software via USB under Windows 11
• digital multimedia teaching material online: E–Learning course, worksheets
