Mechanically Refrigerated Cold Filter Plugging Point Bath for Oil Fuel and Petroleum Testing Instruments

The Cold Filter Plugging Point (CFPP) Apparatus determines the low-temperature flow characteristics of automotive diesel fuels and gas oils, including samples containing flow-improving additives. It measures the temperature at which the sample ceases to flow through a wire mesh filter under standard test conditions. The apparatus consists of a Cold Filter Plugging Point Apparatus, vacuum system, and cooling bath, with a choice of mechanically refrigerated or dry-ice-cooled models. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum fuel testing applications.

Main Components:

• Cold Filter Plugging Point Apparatus
• Vacuum System
• Cooling Bath

Cold Filter Plugging Point Apparatus:

• Borosilicate glass test jar with graduations
• Brass jacket with plastic support ring
• Plastic stopper
• Plastic insulating ring and spacer
• Pipette
• Brass filter unit with stainless steel fine wire mesh screen

Vacuum System:

• Connects to the Cold Filter Plugging Point Apparatus to draw the sample through the filter screen
• U-tube manometer (without mercury)
• Three-way stopcock
• Air vent tube
• Cork stopper with elbows
• Large glass bottle
• Vacuum pump not included

Cooling Bath Options:

Mechanically Refrigerated Model:

• Cascade hermetic cooling system
• Temperature capability down to –90°F (–68°C)
• Composition top plate for inserting the Cold Filter Plugging Point Apparatus
• Insulated stainless steel tank
• Polished stainless steel cabinet

Dry-Ice-Cooled Model:

• Insulated copper interior
• Steel exterior with corrosion-resistant polyurethane enamel finish
• Composition top plate suspends the apparatus at the required depth in the freezing mixture
• Exterior handles for easy emptying of the freezing mixture
• Thermometer holder included

Dimensions (L × W × H):

Mechanically Refrigerated Model:

• 35 × 26 × 31 inches (89 × 66 × 78.75 cm)

Dry-Ice-Cooled Model:

• Diameter × Height: 12 × 12 inches (30 × 30 cm)

Net Weight:

• Mechanically Refrigerated Model: 259 lbs (117.75 kg)
