Mechanically Refrigerated Freezing Point Bath for Oil Fuel and Petroleum Testing Instruments

The Aviation Fuel Freezing Point Bath determines the temperature below which solid hydrocarbon crystals form in aviation fuels. The freezing point is the lowest temperature at which the fuel remains free of solid hydrocarbon crystals that could restrict fuel flow. During testing, the fuel sample is cooled with continuous stirring in a Dewar-type sample tube until crystals appear. The redesigned constant-temperature bath supports freezing point determinations at temperatures as low as –100°F (–73°C). It features microprocessor-based PID digital temperature control, dual digital displays, selectable Fahrenheit or Celsius scales, and enhanced safety features. The bath uses air-cooled hermetic compressors with CFC-free refrigerants and a motorized stirrer for uniform temperature distribution without turbulence. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for aviation fuel testing applications.

Temperature Range:

• Ambient to –100°F (–73°C)

Temperature Control:

• Microprocessor PID digital temperature control
• Temperature control accuracy and uniformity exceed ASTM requirements throughout the operating range
• Dual digital displays show setpoint and actual bath temperature
• Selectable temperature scale: Fahrenheit or Celsius
• Display resolution: 0.1°C/°F

Bath Capacity:

• 10 liters (2.64 gallons)

Construction and Features:

• Clear, evacuated Dewar flask for the bath medium
• Glare-free fluorescent backlighting for sample visibility
• Air-cooled hermetic compressors using CFC-free refrigerants
• Motorized stirrer ensures complete circulation without turbulence
• Polyester-epoxy-finished steel cabinet
• Chemical-resistant composite top surface
• Working surface includes a port and mounting plate for the freezing point apparatus and accessory stirrer
• Adjustable leveling feet
• Push-button controls for easy temperature setting and monitoring

Power Supply:

• 220–240 V, 50 Hz, single phase, 10.0 A
• 220–240 V, 60 Hz, single phase, 10.0 A

Dimensions (L × W × H):

• 35 × 26 × 31 inches (89 × 66 × 78.75 cm)

Net Weight:

• 255 lbs (115.7 kg)
