Mechanics Comprehensive Physics Lab Experiment Setup by ATICO EXPORT

This experiment system is designed for university-level physics laboratories and provides a comprehensive platform for studying mechanics, material properties, motion analysis, force measurement, and sensor applications. The system integrates a wide range of classical and modern physics experiments, enabling students to develop practical skills while gaining a deeper understanding of fundamental physical principles.

Manufactured by Atico Export India.

Experimental Principle and Content

• Length Measurement, Density Measurement, Simple Pendulum, Three-Line Pendulum, and Torsion Pendulum Experiments
• Newton’s Second Law, Collision Experiments, Compound Pendulum, and Inverted Pendulum Studies
• Investigation of Force-Sensitive Sensor Characteristics and Electronic Scale Design
• Measurement of Young’s Modulus Using the Laser Optical Lever Tensile Method
• Measurement of Solid Density and Real-Time Liquid Density
• Measurement of Sound Velocity and Study of String Vibrations
• Determination of the Moment of Inertia of Rigid Bodies
• Investigation of Sliding Block Motion on an Inclined Air-Cushion Guide Rail and Rigid Body Rotation
• Study of Position Sensor Characteristics and Measurement of Young’s Modulus Using the Bending Beam Method
• Measurement of Gravitational Acceleration and Dynamic Determination of Young’s Modulus

Force-Sensitive Sensor :

• Measuring Range: 0–100 g
• Accuracy: ±0.01 g

Digital Millisecond Timer :

• Laser Photoelectric Gate Timing
• Touch Switch
• 6-Digit LED Display
• Counting Range: 0–99
• Timing Range: 0–999.999 s
• Resolution: 1 ms

DDS Signal Source :

• Frequency Range: 0–100 kHz
• Continuously Adjustable
• Digital Frequency Display

Frequency Adjustment :

• Fine Adjustment: ±0.01 Hz
• Frequency Stability: ±0.01 Hz

Voltage Output :

• 2–18 V (1 A)
• 3½-Digit Digital Display
• Short-Circuit Protection

Measurement Instrument :

• Digital Multifunction Meter for Current, Voltage, and Resistance Measurement

Signal Source Amplifier :

• Built-In High-Sensitivity Amplifier Circuit
• Output Power Greater Than 10 W
