Melting Pot

Usage :

• Suitable for laboratory experiment

Construction :

• Solid-Robust Construction

Bowl and Ladle :

• Metallic Bowl & Ladle. Bowl is used to carry capping compound and ladle is used to pout molten capping compound in to the groves between specimen and capping plate.

Capping Compound :

• Used for capping the ends of concrete cylinders to be tested. Available in packs of 5 kg.

Dimensions (Diameter x Depth) :

• 140 x 150 mm (Internal)
• 250 x 165mm (External)

Capacity :

• 2.4 ltrs. approx.

Temperature Range :

• 40 to 340° C

Rated Power :

• 750 W

Power Supply :

• 220 VAC, 50 Hz, Single Phase
