Michelson Interferometer for Physics Lab

Michelson Interferometer is designed for educational institutions and precision optical experiments. The instrument is mounted on a heavy cast iron base for stable and reliable operation.

Various components are manufactured using high-precision machines and mounted on an aluminum base. The complete interferometer assembly is securely mounted on a heavy cast iron base.

The setup consists of beam splitter and compensator plates mounted in an aluminum housing. The assembly is positioned at 45° to two reflecting mirrors.

All flat optical components have a flatness of at least λ/4 and are protected with a silicon monoxide coating.

Physics Lab Experiments Setup from Atico Exports.

Base :

• Heavy Cast Iron Base

Beam Splitter and Compensator Plates :

• Mounted in an Aluminum Housing
• Positioned at 45° to Two Reflecting Mirrors

Optical Flatness :

• At Least λ/4

Protective Coating :

• Silicon Monoxide Coating

Least Count :

• 0.01 mm

Reading Telescope :

• Magnification: 3X
• Ramsden Eyepiece
• Cross-Line Graticule

Objective :

• Magnification: 20X
• Supplied with Mount
• Suitable for Experiments Using He-Ne Laser or Diode Laser
