Michelson Interferometer Optics Educational Kits

The Michelson Interferometer Apparatus is a fundamental optical instrument designed for the study of interference and wave optics. By splitting a beam of monochromatic light into two separate paths and recombining them, the system produces interference fringes that can be used for highly accurate optical measurements. The apparatus enables students to investigate wavelength, wavelength separation, refractive index, and various interference phenomena. The precision mirror adjustment system provides smooth movement and accurate control, making the instrument suitable for advanced laboratory experiments and optical measurements. An optional VGA camera system allows real-time observation and display of interference fringes on monitors, projectors, or computers, enhancing both classroom demonstrations and laboratory investigations. Physics Lab Experiments from Atico Exports.

Experiments :

• Interference Fringe Observation
• Equal-Inclination Fringe Observation
• Equal-Thickness Fringe Observation
• White-Light Fringe Observation
• Measurement of Sodium D-Line Wavelength
• Measurement of Sodium D-Line Wavelength Separation
• Determination of the Refractive Index of Air
• Real-Time Interference Fringe Display Using VGA Camera (Optional)

Beam Splitter & Compensator Flatness :

• 0.1 λ

Coarse Mirror Travel :

• 10 mm

Fine Mirror Travel :

• 0.25 mm

Fine Adjustment Resolution :

• 0.5 μm

Weight :

• Approx. 20 kg

Dimensions :

• 350 × 350 × 245 mm

Sodium-Tungsten Lamp :

• Sodium Lamp: 20 W
• Tungsten Lamp: 30 W, Adjustable

He-Ne Laser :

• Output Power: >1.5 mW
• Wavelength: 632.8 nm

Air Chamber Length :

• 80 mm

Pressure Range :

• 0–40 kPa

Optional VGA Camera Specifications :

Sensor Size :

• 1/3"

Resolution :

• 1920 × 1024 Pixels

Pixel Size :

• 2.8 μm × 2.8 μm

Crosshair Lines :

• Up to 32 Adjustable Lines

Output Format :

• VGA

Controls :

• Rear Keypad and Menu System

Interferometer Main Frame :

• Quantity: 1

Ground Glass Screen :

• Quantity: 1

Alignment Aperture :

• Quantity: 1

Sodium-Tungsten Lamp with Power Supply :

• Quantity: 1 Set

He-Ne Laser with Power Supply :

• Quantity: 1 Set

Air Chamber with Gauge :

• Quantity: 1 Set

Manual Counter :

• Quantity: 1

• Smooth Mirror Movement
• High Precision Measurements
• Includes He-Ne Laser, Sodium-Tungsten Lamp, and Air Chamber
• Optional VGA Camera for Fringe Display and Projection
• Suitable for Advanced Interference Experiments
• Detailed Instruction Manual
