Micro Carbon Residue Tester for Oil Fuel and Petroleum Testing Instruments

The Carbon Residue Tester determines the amount of carbon residue formed after the evaporation and pyrolysis of petroleum materials under specified conditions. The results provide an indication of the relative coke-forming tendency of petroleum products. The system features a furnace temperature range from ambient temperature to 550°C, automatic atmosphere control, and temperature measurement resolution of 1°C. Furnace cooling is performed by compressed air injection. The unit accommodates up to 12 small vials or 6 large vials per test cycle. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum testing and carbon residue analysis applications.

Temperature Range:

• Ambient to 550°C

Maximum Test Temperature:

• 550°C

Temperature Measurement Resolution:

• 1°C

Furnace Cooling:

• Compressed air injection

Atmosphere Control:

• Automatically controlled atmosphere

Sample Capacity:

• 12 small vials
• 6 large vials

Operating Conditions:

• Ambient temperature: 15°C to 30°C
• Ambient relative humidity: Maximum 85% (non-condensing)

Power Consumption:

• 1500 W

Dimensions (L × W × H):

• 9.8 × 11.8 × 23.6 inches (25 × 30 × 60 cm)

Net Weight:

• 43 lbs (19.5 kg)
