Micro Separometer for Oil Fuel and Petroleum Testing Instruments

The Rust Preventing Characteristics Tester is designed to evaluate the corrosion-preventing properties of petroleum products used in product pipelines. It helps assess corrosion caused by moisture condensed from gasoline and distillate fuels. Testing is performed by immersing polished steel test specimens in a stirred mixture of the sample and distilled water maintained at a constant temperature. The six-place constant-temperature bath accommodates six sample beakers and provides stirring at 1000 RPM with temperature stability of ±0.5°C (±1°F). It features microprocessor temperature control, a switchable °C/°F digital display, and over-temperature protection. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum corrosion testing applications.

Testing Capacity:

• Six 400 mL sample beakers

Temperature Control:

• Maximum temperature: 104°C (220°F)
• Temperature control stability: ±0.5°C (±1°F)
• Microprocessor temperature control
• Switchable Celsius/Fahrenheit digital setpoint and display
• Over-temperature protection automatically interrupts power when the programmed cut-off temperature is exceeded

Heating System:

• Heater range: 0–1500 W

Drive System:

• Explosion-proof, ball-bearing drive motor
• Stirring speed: 1000 RPM
• Stainless steel stirrer paddles
• Improved pulley and roller-bearing drive arrangement
• Paddles can be raised for convenient placement of sample beakers
• Long-lasting polyester drive belt
• Removable steel guard protects drive-train components

Construction:

• Stainless steel bath
• Perforated support shelf for beakers
• Cover plate
• Stainless steel or chemical-resistant polyurethane enamel exterior finishes

Bath Medium:

• 11 gallons (41.6 L) white technical oil

Standard Accessories:

• Steel test specimens: 6
• Type 2 plastic specimen holders: 6
• Plastic beaker covers: 6

Dimensions (L × W × H):

• 32.75 × 14.25 × 27 inches (83 × 36 × 69 cm)

Net Weight:

• 79 lbs (35.8 kg)
