Microcontroller Trainer

• Microcontroller trainer designed for educational institutes and individuals
• Includes microcontroller module with I/O ports, DC power supply module and application modules
• Provides complete software package for programming, editing, assembling, compiling and execution

Main Frame :

• Microcontroller board built into main frame
• Provides visibility with controlled access
• Socket type I/O ports provided
• DC power supplies for +5 V, -5 V, +12 V, -12 V and GND
• Reset and restart button accessible
• Computer interfacing connectors avail
• Input voltage : AC 240 V, 50 Hz

Accessories :

• Power cord with fused mains plug
• Technical data and programming manuals
• RS 232 interfacing cable
• Instruction manuals and circuit diagrams with soft copy

Application Modules :

Includes built in modules powered by main unit

Module 1 : 8 Bits Data Display Module :

• 8 input sockets with LED indicators
• Used for monitoring output port status

Module 2 : 8 Bits Switch Input Module :

• Toggle switches with output sockets
• Used for input data

Module 3 : 7 Segment Display Module :

• Two 7 segment displays with driver IC

Module 4 : Digital to Analog Converter Module :

• 8 bit DAC with amplifier output

Module 5 : DC Motor Control Module :

• DC motor with relay control and PWM circuit

Module 6 : Stepper Motor Control Module :

• Stepper motor with buffer IC and LED indication

Module 7 : Keypad Module :

• 12 key matrix keypad

Module 8 : Dot Matrix Display Module :

• Dot matrix display with buffer control

Module 9 : LCD Display Module :

• LCD panel 2 x 16 characters

Module 10 : Trigger Sensors and Alarm Circuit Module :

• Photo coupled inputs with buzzer and lamp

Module 11 : Car Park System Application Module :

• Infrared detectors, motor gates and display for simulation

Interface Software :

• Monitor code and software utilities provided
• Assembler program
• Disassembler and memory editor utilities
• Program files for microcontroller

• Integration development environment program
• Display of internal architecture
• Edit, assemble, compile, download and run programs
• Supports C language and assembly language debugging
• Program trace and break functions
• Code memory disassemble function
• Register and memory dump and editing function
• Program scroll display and pop up menu
• Program stop using ESC key
• Supports multiple microcontroller writing functions
• Keyboard and mouse operation
• I/O experiments using C language
• Various I/O port experiments
• Dot matrix experiments
• DC motor and step motor experiments using DAC
• Voltmeter experiment using ADC
• Sound experiment
• Keyboard and LCD display function
• Power supply support for +5 V, -5 V, +12 V, -12 V

Additional Features :

• Standard CPU clocked at high frequency
• 50 I/O lines with socket type ports
• SRAM for program variables and code
• Flash ROM for non volatile storage
• Supports multiple baud rates
• LCD display support
• Dedicated LED indicators
• Bus expansion capability for additional peripherals
• Monitor program for easy development
