Mini Vertical Electrophoresis Unit ALB336

Mini vertical electrophoresis unit designed to accommodate glass plates measuring 101 × 82 mm for efficient electrophoretic procedures. The large buffer capacity provides effective cooling and maintains stable pH throughout the experiment. It features a protective strip on the positive electrode to prevent bubble formation and protect the platinum electrode from damage. Manufactured by Atico Export India.

• Molecular biology.
• Life science.
• Educational institutions.
• Research laboratories.
• Diagnostic laboratories.
• Protein sample analysis.
• Nucleic acid purification.
• Seed purity testing.
• High-throughput SSR marker analysis.

Gel Area (W × L) :

• 81 × 73 mm

Glass Plate Area (W × L) :

• 101 × 82 mm

Buffer Volume :

• 1200 mL

Number of Samples :

• 11 to 60

Gel Making Mode :

• Gel casting

Gel Thickness :

• 1 mm

Amount of Gel :

• 1 to 4 pieces

Dimensions (L × W × H) :

• 175 × 175 × 100 mm

Weight :

• 2.5 kg

• Runs 1 to 4 gel plates simultaneously.
• Fast setup time (15 seconds).
• Automatic power-off when the lid is removed for safe operation.
• Colored sample background for easy sample loading.
