Mixer Mill (Net weight – 60 kg NANO)

The Mixer Mill (Net weight – 60 kg NANO) is a compact, versatile bench-top unit which has been developed specially for dry, wet and cryogenic grinding of up to 2 x 45 ml sample material within seconds. With a maximum frequency of 35 Hz, it generates enough energy to produce particles in the nanometer range.
The Mixer Mill (Net weight – 60 kg NANO) is a unique mixer mill in the market to provide a real alternative to grinding in a planetary ball mill – with more comfortable handling and less warming effects.

HIGH SPEED BALL MILLING WITH EASY OPERATION FOR BEST RESULTS

• Max. speed 35 Hz
• Horizontal oscillation causes strong impact effects for effective sample processing
• Up to 10 mm feed size and 0.1 °m final fineness
• 2 grinding stations for jars of min. 2 ml and max. 125 ml, adapter for 18 x 2 ml single use vials
• Steel jars can be precooled manually in liquid nitrogen
• Grind Control to measure temperature and pressure inside the jar.
• Aeriation lids to control the atmosphere inside the jar
• Bench top model, touch screen, easy jar clamping, jars can stay clamped for subsampling, storable SOPs and cycle - programs, 4 different jar materials for dry and wet grinding

FUNCTIONAL PRINCIPLE

The grinding jars of the Mixer Mill (Net weight – 60 kg NANO) perform radial oscillations in a horizontal position. The inertia of the grinding balls causes them to impact with high energy on the sample material at the rounded ends of the grinding jars and pulverize it. Also, the movement of the grinding jars combined with the movement of the balls result in the intensive mixing of the sample. The degree of mixing can be increased even further by using several smaller balls.

Applications :

• mechanochemistry, mechanical alloying, size reduction, mixing, homogenization, cryogenic grinding

Field of application :

• agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals

Feed material :

• hard, medium-hard, soft, brittle, elastic, fibrous

Size reduction principle :

• impact, friction

Material feed size :

• <= 10 mm

Final fineness :

• ~ 0.1 °m

Batch size / feed quantity :

• max. 2 x 45 ml

No. of grinding stations :

• 2

Vibrational frequency :

• 3 - 35 Hz (180 - 2100 min-1)

Typical mean grinding time :

• 30 s - 2 min

Dry grinding :

• yes

Wet grinding :

• yes

Cryogenic grinding :

• yes

Cell disruption with reaction vials :

• no

Type of grinding jars :

• screw-lock jar with integrated safety closure devices, multi cavity jar, adapter for safe-lock reaction vials

Material of grinding tools :

• hardened steel, stainless steel, tungsten carbide, zirconium oxide

Grinding jar sizes :

• 10 ml / 25 ml / 50 ml / 80 ml / 125 ml

Setting of grinding time :

• digital, 10 s - 8 h

Total grinding time :

• 99 h

Storable SOPs :

• 12

Number of storable :

• cycle programs 4 (with 99 repeats)

Electrical supply data :

• 100-120 V, 50/60 Hz; 200-230 V, 50/60Hz

Power connection :

• 1-phase

Protection code :

• IP 30

Power consumption :

• 750 W

W x H x D closed :

• 690 x 375 x 585 mm

Net weight :

• ~ 60 kg

Standards :

• CE
