MOMENT DISTRIBUTION COEFFICIENT

The model is built on a pressed steel base with plastic piers that support a single span flexible steel beam on swivelling bearings which can accommodate horizontal movement while enabling external moments to be applied and measured. An inserted locking pin makes a fixed end. Rotation of the beam at the support is shown by a large coloured pointer moving across a dual scale, the coarse one being readily seen at 10m distance. Learn about MOMENT DISTRIBUTION COEFFICIENT equipment for optimal educational outcomes.. The set of weights needed for the experiment is included.

• Demonstration model of moment distribution coefficients and carry-over moment
• Bench-top, lecture room model built on a steel base with plastic piers
• Spring steel strip beams supported on swivelling bearings; insertable locking pins supplied for fixed ends
• Rotations clearly marked on simple scales
• Set of weights: 4 x 5N
• Two 0.5N load hangers
• Designed to be readily seen at over 10m distance
• Supplied with detailed instruction manual and laboratory sheet for student use
• 3 year warranty
