Multi Process Control Trainer Level Flow Temperature and Pressure

Investigation of relationships:

• Between manipulated variable and dependent variable
• Between disturbance and manipulated variable
• Between manipulated variable and dependent variable (combined)

Closed Loop Control Systems:

• ON/OFF Level Control Process
• ON/OFF Flow Control Process
• ON/OFF Temperature Control Process
• ON/OFF Pressure Control Process

Control Modes:

• Single Loop & Continuous Closed Loop Control (Automatic Mode)
• ON/OFF Level Control
• ON/OFF Flow Control
• ON/OFF Temperature Control
• ON/OFF Pressure Control
• PID Control

• Fault Conditions & Troubleshooting:
• Heater troubleshooting
• Water flow sensor troubleshooting
• Water temperature troubleshooting
• Water tank water level troubleshooting
• Rotameter troubleshooting
• Radiation temperature troubleshooting
• Water pump troubleshooting
