Multi Sample Kinematic Viscosity Bath

The Kinematic Viscosity Bath is designed for precise determination of the kinematic viscosity of lubricating oils, fuels, and other liquid samples. It features a PID-controlled temperature regulation system with an operating range from room temperature to 120°C, ensuring excellent temperature stability for accurate testing. Equipped with four bath holes and an LCD display, it enables simultaneous testing of multiple samples while providing real-time monitoring of operating parameters. Manufactured by Atico Export India.

• Lubricating oil testing
• Fuel analysis
• Petroleum laboratories
• Quality control laboratories
• Research and development laboratories
• Industrial testing laboratories
• Chemical laboratories
• Kinematic viscosity determination

Temperature Range :

• RT to 120°C

Temperature Range Precision :

• ≤±0.1°C

Temperature Control Precision :

• RT to 40°C: ≤±0.2°C

Liquid Bath Holes :

• 4

Test Time :

• 1 to 6 Times (Adjustable)

Bath Fiber Glass Thickness :

• 4 mm

Bath Fiber Glass Diameter :

• 245 mm

Bath Height :

• 250 mm

Power Supply :

• AC 220 V ±10%, 50 Hz

Power Consumption :

• 1000 W

Bath Dimensions :

• 590 × 450 × 460 mm

Machine Dimensions :

• 410 × 310 × 390 mm

Net Weight :

• 14 kg

• PID temperature controller
• LCD display for real-time monitoring
• Four-bath hole design for simultaneous testing
• Durable laboratory construction
• Adjustable testing duration
• Data storage support
• Complies with ASTM D445 standard
• Accurate temperature regulation
• Stable and reliable performance
