Multifunctional Grating Spectrometer Monochromator for Spectral Physics Instruments

The Multifunctional Grating Spectrometer Monochromator for Spectral Physics Instruments is a versatile optical instrument designed for the study of spectroscopy, optical measurements, and wave phenomena. Its modular architecture allows users to adapt the instrument to a variety of experimental requirements by selecting different gratings, detectors, and accessories. The system supports both photomultiplier tube (PMT) and CCD detection modes, enabling either highly sensitive signal detection or real-time spectral acquisition. A mechanical switching system allows convenient selection between operating modes. When the CCD detector is removed, the instrument can also function as a precision monochromator for accurate wavelength selection and measurement. Light entering the spectrometer is dispersed by a diffraction grating into its component wavelengths. The selected detector captures the resulting spectrum for analysis, allowing users to perform qualitative and quantitative optical investigations. Optional accessories further expand the system’s capabilities for absorbance measurements and fiber optic applications. Physics Lab Experiments from Atico Exports.

Experimental Applications:

1. Spectral Analysis

• Measure and analyze emission spectra from various light sources
• Study absorption spectra of different materials
• Perform qualitative and quantitative spectral investigations

2. Monochromator Applications

• Use as a high-precision monochromator
• Perform wavelength selection and optical measurements
• Conduct wavelength-dependent experiments

3. Detector Comparison Studies

• Compare measurements using PMT and CCD detection systems
• Evaluate detector sensitivity and performance characteristics
• Study different spectral acquisition methods

4. Fiber Optic Spectroscopy

• Perform optical measurements using optional fiber optic adapters
• Connect optical fibers to entrance and exit slits
• Analyze remote and guided light sources

5. Absorbance Measurements

• Measure sample absorbance using optional cuvette holders
• Utilize standard laboratory cuvettes
• Perform transmission and absorption studies

6. Spectral Calibration

• Calibrate spectral windows using reference spectral lines
• Verify wavelength accuracy and repeatability
• Improve measurement precision

Focal Length:

• 500 mm

Relative Aperture:

• D/F = 1/7

Slit Width:

• 0 – 2 mm Adjustable
• Reading Resolution: 0.01 mm

Blaze Wavelength:

• 250 nm

Stray Light:

• ≤ 10⁻³

Dimensions:

• 560 × 380 × 230 mm

Weight:

• 30 kg

Software Compatibility:

• Windows 10
• Windows 11

Grating Options:

Grating A

• Wavelength Range: 200 – 660 nm
• Groove Density: 2400 Lines/mm
• Wavelength Accuracy: ±0.2 nm
• Wavelength Repeatability: ≤0.1 nm
• Resolution: ≤0.06 nm

Grating B

• Wavelength Range: 200 – 800 nm
• Groove Density: 1200 Lines/mm
• Wavelength Accuracy: ±0.4 nm
• Wavelength Repeatability: ≤0.2 nm
• Resolution: ≤0.1 nm

Photomultiplier Detector (PMT):

Spectral Range (Grating A):

• 200 – 660 nm

Spectral Range (Grating B):

• 200 – 800 nm

CCD Detector:

Detector Array:

• 2048 Cells

Spectral Response (Grating A):

• 300 – 660 nm

Spectral Response (Grating B):

• 300 – 800 nm

Integration Time:

• 88 Steps
• Approximately 25 ms per Step

Optical Filters:

White Filter:

• Spectral Range: 320 – 500 nm

Yellow Filter:

• Spectral Range: 500 – 660 nm

Parts List:

Grating Monochromator:

• Quantity: 1

Power Control Box:

• Quantity: 1

Photomultiplier Receiving Unit:

• Quantity: 1

CCD Receiving Unit:

• Quantity: 1

USB Cable:

• Quantity: 1

Filter Set:

• Quantity: 1

Power Cord:

• Quantity: 1

Signal Cables:

• Quantity: 2

Software Package:

• Quantity: 1

Optional Accessories:

Cuvette Holder with Dovetails:

• Quantity: 1

Cuvette Holder with Fiber Optic Connectors:

• Quantity: 1

Fiber Optic Adapter for Entrance Slit:

• Quantity: 1

Fiber Optic Adapter for Exit Slit:

• Quantity: 1

• Replaceable Gratings for Different Spectral Ranges and Resolutions
• Modular and Flexible Design
• Dual Detector System: Photomultiplier Tube and CCD
• Optional Fiber Optic Adapters and Cuvette Holders
• High Wavelength Accuracy and Resolution
• Suitable for Research, Education, and Spectral Analysis Applications
