Multimanometer with 12 manometric tubes of 500 mm lenght, vertical position

The Multimanometer with 12 manometric tubes of 500 mm length, vertical position, allows for precise measurement and analysis of pressure variations in vertical configurations, providing valuable data to understand fluid behavior in various environments.

ATENG 11785 — Multimanometer with 12 manometric tubes of 500 mm lenght, vertical position

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

Bench-top unit.

Anodized aluminum frame and panels made of painted steel. Vertical position.

• Main metallic elements made of stainless steel. Eight manometric tubes, length: 500 mm.
• Inclination: 30° approx. Tubes inner diameter: 8 mm, to avoid bubbles.
• Twenty manometric tubes, length: 250 mm. Air pump for pressurization.
• Tubes inner diameter: 8 mm, to avoid bubbles. Eight points for differential pressure measurement, with key.
  Water tank for filling. Common collector.
  Twenty points for differential pressure measurement, with key.
  Non-return valve.
  Common collector.
  Drain valve.
  Drain valve.
• Millimeter precision rules, length: 500 mm.
• Millimeter precision rules, length: 250 mm.
